USE TP - Once you've selected (cycled through) available Terminal Procedures from the list, click here to use that in your flight. This then displays a list of available TP and you can cycle through them. SEARCH TP - Click here to search for available Terminal Procedures with the given settings. To/From Runway - Type in the Procedure's Transition Runway and click here to set it. Terminal Procedure Type - Cycle through SID/STAR/IAP for TP type. Airport ICAO - Type in the Airport ICAO of the Airport you want to find a Terminal Procedure of and click here to set it. Note that this section is still under development and testing. This page is used to search for different terminal procedures from LevelD-767 navdata present in your $FG_ROOT/Aircraft/787-8/FMC-DB/ page. FLIGHT LOG - Takes you to the FLIGHT LOG page. FLIGHT INFO - Takes you to the FLIGHT INFO page. PROCEDURES - Takes you to the TERMINAL PROCEDURE SEARCH page. Type in the flight number and click here to set it. Destination Runway - Type in your destination Runway and click here to set it. Departure Runway - Type in your Departure Runway and Click here to set it. Destination - Type in your Destination ICAO and click here to set it. Departure - Type in your Departure ICAO and click here to set it. Use this page to control your flight data and base for the route manager. Type in a radio frequency and click on the radio setting on the Right side to set that frequency to standby.
Click on the Radio Setting on the Left side to switch between standby and active. This page let's you set Standby Radio Frequencies and Switch them with active ones. Bank Limit - Cycle through different bank limits for the flight envelope protection. Yaw Damper - Click on the right side menu to toggle FBW Yaw Damper. Rudder Control - Click on the right side menu to toggle FBW Rudder Control. Fly By Wire Status - Click on the right side menu to ACTIVATE/DISABLE the fly-by-wire. This page lets you manage the fly-by-wire settings. Chart ID - Cycle through available Terminal Procedures you wish to view in the EFB. Chart Type - Cycle through SID/STAR/IAP for chart type. Airport ICAO - Type in the Airport ICAO of the chart you want and click here to set it. This is a specialized EFB INPUT Sub-page used to select a chart to display in the Airport Charts page. To Send an input into the EFB, type it on the keypad and hit the EXEC/ENTER key. That can include typing in an airport to search for in the Airport Information/Diagram page, Runway to search for in the Runway Information page, Flight information in the Auto-PIREP System page, and selecting charts in the Charts Selection page. This page lets you type in different things that is required by the EFB. End Cruise at - Type in the waypoint you want to descend to right after you get out of the cruise phase and click here to set it. Start Cruise at - Type in the first waypoint in your cruise phase and click here to set it. Cruise Altitude - Type in your cruise altitude and click here to set it.
This page lets your change your Cruise Altitude and VNAV settings.
FLIGHTGEAR 787 MANUAL
EXIT HOLD - Click here to get back manual control from the hold.ENTER HOLD - Click here to start flying the automated hold.SEARCH NAVAID - Click here to search for the navaid you typed in.Turn Direction - Toggle between Left and Right for Turn Direction.Holding Time - Type in the time (seconds) you want to fly the inbound leg and click here to set it.Holding Altitude - Type in the altitude (feet) you want to maintain while holding and click here to set it.Holding Radial - Type in the radial you want to hold at and click here to set it.
Holding Navaid Type - Cycle through VOR/FIX/NDB. Holding Navaid - Type in the Navaid you want to hold at and click here to set it. This page allows you to search hold navaids, set hold settings and enter/exit an automated hold. This page shows the Aircraft Model, Engines Installed and Callsign being used at the moment. APPROACH - Takes you to the APPROACH page. TAKE OFF - Takes you to the TAKE OFFpage. FLIGHTPLAN - Takes you to the FLIGHTPLAN page. DEP/ARR - Takes you to the DEP/ARR page. FBW CONFIG - Takes you to the FBW CONFIG page. EFB INPUT - Takes you to the EFB INPUT page. VNAV CONFIG - Takes you to the VNAV CONFIG page. HOLD CONFIG - Takes you to the HOLD CONFIG page. The INDEX page is the hub of the Control Display Unit from where you can navigate to different pages in the CDU. This image will be used as a reference to help explain different pages on the CDU. Below, we will explain the different pages in the Control Display Unit. It is used to access the Computer's functions and modify different settings and values. The Control Display Unit is a part of the Boeing 787-8 Dreamliner's Flight Management Computer.
